TLS/SSL Connections

Mongoose supports connecting to MongoDB clusters that require TLS/SSL connections. Setting the tls option to true in mongoose.connect() or your connection string is enough to connect to a MongoDB cluster using TLS/SSL:

mongoose.connect('mongodb://127.0.0.1:27017/test', { tls: true });

// Equivalent:
mongoose.connect('mongodb://127.0.0.1:27017/test?tls=true');

The tls option defaults to false for connection strings that start with mongodb://. However, the tls option defaults to true for connection strings that start with mongodb+srv://. So if you are using an srv connection string to connect to MongoDB Atlas, TLS/SSL is enabled by default.

If you try to connect to a MongoDB cluster that requires TLS/SSL without enabling the tls/ssl option, mongoose.connect() will error out with the below error:

MongooseServerSelectionError: connection <monitor> to 127.0.0.1:27017 closed
    at NativeConnection.Connection.openUri (/node_modules/mongoose/lib/connection.js:800:32)
    ...

TLS/SSL Validation

By default, Mongoose validates the TLS/SSL certificate against a certificate authority to ensure the TLS/SSL certificate is valid. To disable this validation, set the tlsAllowInvalidCertificates (or tlsInsecure) option to true.

mongoose.connect('mongodb://127.0.0.1:27017/test', {
  tls: true,
  tlsAllowInvalidCertificates: true,
});

In most cases, you should not disable TLS/SSL validation in production. However, tlsAllowInvalidCertificates: true is often helpful for debugging SSL connection issues. If you can connect to MongoDB with tlsAllowInvalidCertificates: true, but not with tlsAllowInvalidCertificates: false, then you can confirm Mongoose can connect to the server and the server is configured to use TLS/SSL correctly, but there's some issue with the certificate.

For example, a common issue is the below error message:

MongooseServerSelectionError: unable to verify the first certificate

This error is often caused by self-signed MongoDB certificates or other situations where the certificate sent by the MongoDB server is not registered with an established certificate authority. The solution is to set the tlsCAFile option, which essentially sets a list of allowed SSL certificates.

await mongoose.connect('mongodb://127.0.0.1:27017/test', {
  tls: true,
  // For example, see https://medium.com/@rajanmaharjan/secure-your-mongodb-connections-ssl-tls-92e2addb3c89
  // for where the `rootCA.pem` file comes from.
  tlsCAFile: `${__dirname}/rootCA.pem`,
});

Another common issue is the below error message:

MongooseServerSelectionError: Hostname/IP does not match certificate's altnames: Host: hostname1. is not cert's CN: hostname2

The SSL certificate's common name must line up with the host name in your connection string. If the SSL certificate is for hostname2.mydomain.com, your connection string must connect to hostname2.mydomain.com, not any other hostname or IP address that may be equivalent to hostname2.mydomain.com. For replica sets, this also means that the SSL certificate's common name must line up with the machine's hostname. To disable this validation, set the tlsAllowInvalidHostnames option to true.

X.509 Authentication

If you're using X.509 authentication, you should set the user name in the connection string, not the connect() options.

// Do this:
const username = 'myusername';
await mongoose.connect(`mongodb://${encodeURIComponent(username)}@127.0.0.1:27017/test`, {
  tls: true,
  tlsCAFile: `${__dirname}/rootCA.pem`,
  authMechanism: 'MONGODB-X509',
});

// Not this:
await mongoose.connect('mongodb://127.0.0.1:27017/test', {
  tls: true,
  tlsCAFile: `${__dirname}/rootCA.pem`,
  authMechanism: 'MONGODB-X509',
  auth: { username },
});

X.509 Authentication with MongoDB Atlas

With MongoDB Atlas, X.509 certificates are not Root CA certificates and will not work with the tlsCAFile parameter as self-signed certificates would. If the tlsCAFile parameter is used an error similar to the following would be raised:

MongoServerSelectionError: unable to get local issuer certificate

To connect to a MongoDB Atlas cluster using X.509 authentication the correct option to set is tlsCertificateKeyFile. The connection string already specifies the authSource and authMechanism, however they're included below as connect() options for completeness:

const url = 'mongodb+srv://xyz.mongodb.net/test?authSource=%24external&authMechanism=MONGODB-X509';
await mongoose.connect(url, {
  tls: true,
  // location of a local .pem file that contains both the client's certificate and key
  tlsCertificateKeyFile: '/path/to/certificate.pem',
  authMechanism: 'MONGODB-X509',
  authSource: '$external',
});

Note The connection string options must be URL escaped correctly.
